Public EV Charging Infrastructure Solution Charger for Urban Deployment

1 / 5

Public EV Charging Infrastructure Solution Charger for Urban Deployment

Still deciding? Get samples of $ !

Order Sample

Send Inquiry

Product Description

⚡ Overview & Basic Info

Model NO.

QSCDZ

Rated Current

2A; 63A; 100A; 200A; 300A

Rated Power

7kw; 11kw; 22kw; 60kw; 120kw; 180kw; 240kw

Protection Grade

IP54 (Indoor/Semi-Outdoor); IP65 (Universal Outdoor)

Service Life

8 Years; 10 Years

Charging Type

AC Charging; DC Charging; AC&DC Integrated Charging

Charging Efficiency

≥93% (AC Charger); ≥95% (DC Charger)

Power Factor

≥0.95 (Rated Load); ≥0.92 (Light Load)

📦 Product Description

High-Performance Charging Pile

Flexible Expansion & Wide Compatibility
Certified Safety & Rock-Solid Reliability
Effortless Operation & Low-Maintenance Design
Consistently Stable Performance for Efficient Charging

Our charging pile series includes multiple models, with two options: wall mounted and floor standing, to meet different installation needs. Modular power configuration makes them easy to maintain - wall mounted models save space, while floor standing models offer faster charging speeds. Suitable for residential and commercial use.

📋 Specification

Feature	Technical Data
Power Output	20KW 40KW 120KW 160KW 240KW
Input Rating	110V/220V/380V±15%
Working Frequency	50/60±10%
Output Voltage	200~1000V
Connectors	CCS1, CCS2, GB/T, J1772, IEC62196, CHADEMO
Display	7" LCD Touch Screen
Network	4G / Ethernet
Protocol	OCPP1.6J (OCPP2.0 upgradable)
Protection	IP55

🔥 Best Sellers

7KW AC Charger

Compatible with global certifications (CE/UL/PSE/KC)
ISO 15118-20 standard + PNC Plug & Charge
V2G vehicle-to-grid protocol support
Billing accuracy ±0.5%

20KW-40KW DC Charger

80% power replenished in 30 mins
IP65 dustproof & waterproof
Wide temperature adaptation (-30℃ to 60℃)
Supports Apple Pay/Google Pay/Credit Card

120/160/240KW DC Station

Dual-gun simultaneous charging
300+km range replenished in 30 mins
Dynamic power allocation
V2G supported & industrial-grade protection

🔍 Product Details

Multi-standard fast charging connectors (CCS2/Type2/CHAdeMO).
Thickened high-temperature resistant special cables, anti-aging & anti-stretching.
Customizable cable length with self-locking anti-drop connectors.

✨ Key Features & Logistics

🏢 Profile

We are an experienced power equipment manufacturer with over 20 years of industry expertise, serving global markets with reliable power distribution and new energy solutions.

Covers over 16,000 stere with professional technical team.
ISO9001:2000, Environmental & Occupational Health Certifications.
Strict quality control and compliant with global standards (CCC, CQC).
Specializing in distribution cabinets, transformers, and EV charging systems.

❓ Frequently Asked Questions

What situations are not covered by the warranty?

Includes human damage, unauthorized disassembly/modification, use of non-genuine parts, improper installation, external voltage abnormalities, and force majeure events like fire or earthquakes.

Is regular maintenance service provided?

We provide free annual inspections including electrical safety testing, mechanical tightening, and software updates. Quarterly maintenance packages are available for commercial chargers.

Does the service comply with local regulations (GDPR/CE)?

Fully compliant with EU GDPR and local safety certifications (CE/UL/PSE). Maintenance data is encrypted and stored to protect user privacy.

Can the warranty period be extended?

Yes, paid extensions are available: 2 years for residential chargers and 1-3 years for commercial chargers, covering the main unit and core parts.

Is after-sales service universal across different countries?

Our global system covers major markets in Europe, America, Asia-Pacific, and the Middle East. Standard services are available locally using your equipment serial number.

What is the charging efficiency of these units?

Our AC chargers achieve ≥93% efficiency, while our DC chargers reach ≥95%, ensuring minimal energy loss during the charging process.
