Advanced CCS1 Type1 Electric Vehicle Charging Solutions for All

1 / 5

Advanced CCS1 Type1 Electric Vehicle Charging Solutions for All

Still deciding? Get samples of $ !

Request Sample

Send Inquiry

Product Description

Overview & Basic Info

Model NO.

FH-EA-7kW, FH-EA-11kW, FH-EA-22kW

Charging Interfaces

One Pile with One Charge

Location

Private and Public

Installation

Wall Mounted

Charge Method

Normal Charge

AC Input Voltage

230VAC / Single Phase; 400VAC / Three Phase

Output Current

16A, 32A

Output Power

7kw, 11kw, 22kw

Cable Length

Rated 5m (Customized up to 10m)

Authentication

4G, Ethernet, WiFi, Bluetooth

Certification

EMC Class B, TUV CE, CQM, ISO, UL

Warranty

12 Months

Support

Ocpp 1.6 Protocols

Dimensions

300*315*120mm (L*W*H)

Our Advantages

The 7kW-22kW Electric Vehicle Charging Station is a top-tier offering renowned for its AC Type2 standard. This EV charging station boasts a sleek, wall-mounted design with an optional stand column installation. It features an IP54 protection rating, glass protection, a vibrant 7" LCD touch screen, and supports multiple charging modes. It seamlessly integrates with LAN, 4G, and optional LTE wireless communication, ensuring top-notch quality and reliability.

✓

Supports TYPE1, TYPE2, or GBT connectors.

✓

IP54-rated design ensures high protection even in harsh environments.

✓

Versatile installation: Wall-mounted or optional pile-type.

✓

AC charging capacities of 7kW, 11kW, 19kW, or 22kW.

✓

User-friendly interface with a 7'' TFT capacitive touch screen protected by tempered glass.

✓

Equipped with high-precision internal AC and DC energy meters.

✓

Supports RFID authorization and Mobile App payment.

Product Parameters

Product Description

About Our Solutions

Established in 2008, we are a pioneering manufacturer and solution provider in Smart Energy and Smart City domains. Our diverse product range includes EV charging stations, portable power stations, energy storage systems (ESS), UPS, lithium batteries, and micro-grid solutions.

With over a decade of relentless innovation, we lead in R&D investment and product design. We have built robust partnerships across various sectors including government, education, medical, and transportation. Our mission is to enhance the world and contribute to a sustainable future through Electricity, AI, Cloud Computing, and Big Data.

Frequently Asked Questions

Q1: What power ratings are available for these EV charging stations? We offer three main power capacities: 7kW (single-phase), as well as 11kW and 22kW (three-phase) to meet different charging speed requirements.

Q2: Can the charger be installed outdoors? Yes, the units are designed with an IP54 protection rating, making them highly reliable and suitable for both indoor and outdoor environments.

Q3: What types of EV connectors are supported? Our charging stations support universal standards including TYPE1, TYPE2, and GBT connectors to ensure compatibility with most electric vehicles.

Q4: How can users authenticate themselves to start charging? The system supports multiple authentication and payment methods, including RFID cards, Mobile App payment, and various communication protocols like WiFi and Bluetooth.

Q5: What certifications do these products hold? Our products are fully certified by international standards, including EMC Class B, TUV CE, CQM, ISO, and UL, ensuring the highest safety and performance.

Q6: Is remote management available? Yes, the stations support OCPP 1.6 protocols and LAN/4G connectivity, allowing for remote online guidance, monitoring, and OTA (Over-the-Air) updates.
